3″ Blue Polyurethane on Aluminum Wheel – Plate Rigid Caster 3

$22.77

PN: 3PA3X1.25-R
In Stock
Volume Pricing on Inquiry. Call us: 800-501-3808

View cart Request for Quote
Volume Pricing on Inquiry. Call us: 800-501-3808
Most of our casters are assembled and dispatched within 24-48 hours.

Technical Specifications

3
Wheel Diameter
3
1 1/4
Wheel Width
1 1/4
Ball
Wheel Bearing
Ball
250 lbs
Maximum Capacity (lbs)
250 lbs
4 1/8"
Overall Height
4 1/8"
Blue
Color
Blue
PTBTB
Zinc Brake Codes
PTB, TB
LA
Lube Axle Code
LA
Mounting PlateTop Plate
Plate Fastener Type
Mounting Plate, Top Plate
Top Plate
Plate Mounting Type
Top Plate
Weight
Weight
1.75 lbs

Description

Matching rigid caster for Plate Caster Model 3.  The mounting plate is 2 3/8” x 3 5/8” and the hole pattern is slotted to: 1 3/4” x 2 7/8” – 3” and is designed to use a mounting bolt size of 5/16”.  This rigid caster uses a ⅜” diameter axle and nut and uses 1-¼” and 1-½” wide wheels.  Multiple wheels and brake options are available.  When manually moving equipment supported by 4 swivel casters it can be difficult to control the direction you are pushing or pulling.  Rigid casters assist in controlling equipment being moved in straight line travel.  Equipment with rigid casters installed can not move sideways.  This plate caster is NSF listed.

Caster City manufactures this plate caster in Stainless Steel.  Caster City also manufactures this plate caster in Economy Stainless Steel.  Both casters are NSF listed and RoHS Compliant.

The blue (“PA”) polyurethane on aluminum wheel was designed to support some of the highest loads we can offer with a 1-¼” wide industrial caster wheel.  This liquid cast blue polyurethane on aluminum wheel is offered in 1-¼” tread width only and is made in diameters 3”, 3.5”, 4”, and 5”.  The (“PA”) blue polyurethane light duty industrial caster wheel is made from a high quality liquid caster polyurethane and the aluminum center of the wheel will not rust, NSF rated.

Given the same size load on a smooth floor, a polyurethane caster wheel rolls easier than the same size conventional rubber caster wheel.  Polyurethane wheels are chosen when higher loads are needed to roll on floors due to offering more floor protection than what a hard composition caster wheel can.

The Blue Polyurethane on Aluminum caster wheel is a liquid cast polyurethane tire that is chemically bonded to its aluminum center. They are used in almost every type of application, but are especially popular in Research Laboratories, Hospitals, Food Service, Schools, Bakeries and other Institutional applications. This swivel caster can be used in industrial applications which do not involve shock, overloading, abuse, obstructions, poor floors or storage ( standing ) loads. This caster wheel is a non-marking polyurethane which rolls more easily than soft rubbers on smooth floors. The caster wheel has two annular ball bearings for higher capacity easier rolling.

The rated capacity of the 3” wheel is 250lbs under ideal conditions. If the wheel is left parked for a prolonged period, do not exceed 70% of the rated capacity of the wheel to avoid a flat spot from developing. The Durometer is Shore A 95. Caster wheel comes with a dust cover over the bearing.

*Photo shown is with the 5″ Wheel* For more information and help placing an order, give us a call at 800-501-3808.
