3″ Polyolefin Wheel Black Donut – Plate Swivel Caster 3

Description

Plate Caster Model 3 is made using a stamped steel construction and is bright zinc plated for corrosion resistance.  The mounting plate is 2 3/8” x 3 5/8” and the hole pattern is slotted to: 1 3/4” x 2 7/8” – 3” and is designed to use a mounting bolt size of 5/16”.  This plate caster uses a ⅜” diameter axle and the swivel caster is held together by a 1⁄2” diameter rivet.  This institutional plate caster is constructed with two ball bearings on hardened raceways to ensure life of the caster.  There is a metal dust cap protecting the swivel raceways to shield them from dirt and dust.  Features wheels with 1-¼” and 1-1⁄2” tread widths.  This Zinc Plated caster is NSF listed.

Caster City manufactures this plate caster in Stainless Steel Caster Model 3.  This caster comes standard with two high temperature white seals in the swivel bearing that has a temperature range of -20F to 450F.  Also come with a grease fitting on the dust cover and axle, and buffed to a smooth reflective surface.

Caster City also manufactures this plate caster in Economy Stainless Steel Plate Caster Model K3.  Constructed with S304 stainless steel and comes with no dust cap or grease fitting on the swivel making it economically efficient for most applications.

Black Donut Polyolefin Caster Wheels are injection molded from a blend of thermoplastic polymers forming a one piece solid sanitary design. This wheel comes with a shielded ball bearing, and these Polyolefin wheels are especially suited for wet and corrosive applications. They are very resistant to most commonly encountered liquids. Polyolefin wheels have a lower capacity and a more limited temperature range than Nylon wheels. In a cold dry environment, such as a refrigerated store room, Polyolefin wheels may become brittle. They should not be used in a freezer or a heat application above 180°F intermittent usage, such as a rack washer.  Polyolefin wheels can not develop a flat spot when parked for prolonged periods.

This donut shaped wheel comes with sealed ball bearings in the wheel. It’s tread shape enables it to change directions much more easily.

*Photo and video shown is with the 5″ Wheel* For more information and help placing an order, give us a call at 800-501-3808.
