Stem Caster Model 3

Caster City ships all casters from Texas, Ohio, or Washington.

Capacity up to 300 pounds per caster. These institutional stem casters are ideal for most types of institutional equipment, and are offered with a wide selection of wheels.

Click Links Below for 2D Drawing of Stem Caster Model 3:

2D PRINT – 3″ Swivel Caster (Mounting Height and Swivel Radius)

2D PRINT – 4″ Swivel Caster (Mounting Height and Swivel Radius)

2D PRINT – 5″ Swivel Caster (Mounting Height and Swivel Radius)

Stem # ID of Tubing Rubber Range ( smallest size to largest size )
ER9 3/4″ .720″ to .851″
ER27 7/8″ .852″ to .927″ fits 1″ O.D. 16 or 18 Gauge
ER28 1″ .928″ to 1.029″
ER7A 1 1/16″ 1.020″ to 1.100
ER29 1 1/8″ 1.100″ to 1.180″
ER17 1 1/4″ 1.178″ to 1.303″
ER25 1 3/8″ 1.360″ to 1.425″
ER26 1 1/2″ 1.426″ to 1.589″ fits 1 5/8″ O.D. 16 or 18 Gauge
ER21 1 13/16″ 1.790″ to 1.850″
Stem # Threaded Stem Size Threaded Stem Length
TS21 1/2″ – 13″ 1″
TS22 1/2″ – 13″ 1 1/2″
TS26N 1/2″ – 13″ 2 3/4″
TS61 3/8″ – 16″ 1″
TSC1 1/2″ – 13″ 4″
TS5/8 5/8″ – 11″ 1 3/4″
TSC2 5/8″ – 11″ 4″
TS3/4 3/4″ – 10″ 1 3/4″
TSC3 3/4″ – 10″ 6″
HK1/2 1/2″ HOLLOW KINGPIN 1/2″ SLIP FIT / HOLE FOR YOUR BOLT

Stem Caster Model 3 Chart
(Click the Part Number to Order)

We do NOT include mounting Hardware.

Desktop: When you put your mouse over the words in the wheel description column you see a picture of the wheel. Click on the part number in the Swivel and Rigid columns to see the complete caster.

Mobile: Hold down your finger on the chart and scroll to the right to click on the part number you would like to order.

Filter through the Available Diameters to find the size you need.

CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL STD BRG TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
3″ 1 1/4″ Gray Soft Rubber
PS 150 3RF3X 2 1/4 2 7/8″ 4″
3″ 1 1/4″ Super Soft Gray Soft Rubber
B 105 3RS3X 2 1/4 2 7/8″ 4″
3″ 1 1/4″ High Capacity Rubber
B 200 3RH3BX 2 1/4 2 7/8″ 4″
3″ 1 1/4″ Maroon/Gray Premium Polyurethane
B 250 3PM3X 2 1/4 2 7/8″ 4″
3″ 1 1/4″ Gray Polyurethane
PS 200 3GP3X 2 1/4 2 7/8″ 4″
3″ 1 1/4″ Black/Gray Polyurethane
PS 200 3BK3X 2 1/4 2 7/8″ 4″
3″ 1 1/4″ Blue/Gray Polyurethane
PS 200 3BP3X 2 1/4 2 7/8″ 4″
3″ 1 1/4″ Red/Gray Polyurethane
PS 200 3RG3X 2 1/4 2 7/8″ 4″
3″ 1 1/4″ All Polyurethane
D 200 3AP3X 2 1/4 2 7/8″ 4″
3″ 1 1/4″ Blue Polyurethane on Aluminum
B 250 3PA3X 2 1/4 2 7/8″ 4″
3″ 1 1/4″ Polyolefin – Black
P 250 3PB3X 2 1/4 2 7/8″ 4″
3″ 1 1/4″ Polyolefin – Black Donut
B 250 3PB3BX 2 1/4 2 7/8″ 4″
3″ 1 1/4″ Nylon ( White )
B 300 3NY3BX 2 1/4 2 7/8″ 4″
3″ 1 1/4″ Phenolic
P 250 3TM3X 2 1/4 2 7/8″ 4″
3″ 1 1/4″ Hard Rubber
B 200 3RN3X 2 1/4 2 7/8″ 4″
3″ 1 1/4″ Gray Iron
P 250 3CL3X 2 1/4 2 7/8″ 4″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL STD BRG TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
4″ 1 3/8″ Blue Soft Rubber
RB 250 3RC4X 2 3/4 3 1/4″ 5″
4″ 1 1/4″ Gray Soft Rubber
PS 200 3RF4X 2 3/4 3 1/4″ 5″
4″ 1 1/4″ Super Soft Gray Soft Rubber
B 120 3RS4X 2 3/4 3 1/4″ 5″
4″ 1 1/4″ High Capacity Rubber
B 250 3RH4BX 2 3/4 3 1/4″ 5″
4″ 1 1/4″ Maroon/Gray Premium Polyurethane
B 300 3PM4X 2 3/4 3 1/4″ 5″
4″ 1 1/4″ Gray Polyurethane
PS 250 3GP4X 2 3/4 3 1/4″ 5″
4″ 1 1/4″ Black/Gray Polyurethane
PS 250 3BK4X 2 3/4 3 1/4″ 5″
4″ 1 1/4″ Blue/Gray Polyurethane
PS 250 3BP4X 2 3/4 3 1/4″ 5″
4″ 1 1/4″ Red/Gray Polyurethane
PS 250 3RG4X 2 3/4 3 1/4″ 5″
4″ 1 1/4″ All Polyurethane
D 250 3AP4X 2 3/4 3 1/4″ 5″
4″ 1 1/4″ Blue Polyurethane on Aluminum
B 300 3PA4X 2 3/4 3 1/4″ 5″
4″ 1 1/4″ Polyolefin – Black
P 300 3PB4X 2 3/4 3 1/4″ 5″
4″ 1 1/4″ Polyolefin – Black Donut
B 300 3PB4BX 2 3/4 3 1/4″ 5″
4″ 1 1/4″ Nylon ( White )
B 300 3NY4BX 2 3/4 3 1/4″ 5″
4″ 1 1/4″ Phenolic
P 300 3TM4X 2 3/4 3 1/4″ 5″
4″ 1 1/4″ High Temp Glass Filled Nylon
P 300 3NP4X 2 3/4 3 1/4″ 5″
4″ 1 1/4″ High Temp Phenolic – Fiberglass
P 300 3TP4X 2 3/4 3 1/4″ 5″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL STD BRG TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
5″ 1 1/4″ Gray Soft Rubber
PS 250 3RF5X 3 1/4 4″ 6 1/8″
5″ 1 1/4″ Super Soft Gray Soft Rubber
B 125 3RS5X 3 1/4 4″ 6 1/8″
5″ 1 1/4″ High Capacity Rubber
B 250 3RH5BX 3 1/4 4″ 6 1/8″
5″ 1 1/4″ Maroon/Gray Premium Polyurethane
B 300 3PM5X 3 1/4 4″ 6 1/8″
5″ 1 1/4″ Gray Rubber ( Crown )
PS 250 3RD5X 3 1/4 4″ 6 1/8″
5″ 1 1/4″ Gray Polyurethane
PS 250 3GP5X 3 1/4 4″ 6 1/8″
5″ 1 1/4″ Black/Gray Polyurethane
PS 250 3BK5X 3 1/4 4″ 6 1/8″
5″ 1 1/4″ Blue/Gray Polyurethane
PS 250 3BP5X 3 1/4 4″ 6 1/8″
5″ 1 1/4″ Red/Gray Polyurethane
PS 250 3RG5X 3 1/4 4″ 6 1/8″
5″ 1 1/4″ Gray Polyurethane ( Crown )
PS 250 3GPC5X 3 1/4 4″ 6 1/8″
5″ 1 1/4″ All Polyurethane
D 300 3AP5X 3 1/4 4″ 6 1/8″
5″ 1 1/4″ Blue Polyurethane on Aluminum
B 300 3PA5X 3 1/4 4″ 6 1/8″
5″ 1 1/4″ Polyolefin – Black
P 300 3PB5X 3 1/4 4″ 6 1/8″
5″ 1 1/4″ Polyolefin – Black Donut
B 300 3PB5BX 3 1/4 4″ 6 1/8″
5″ 1 1/4″ Nylon ( White )
B 300 3NY5BX 3 1/4 4″ 6 1/8″
5″ 1 1/4″ Phenolic
P 300 3TM5X 3 1/4 4″ 6 1/8″
5″ 1 1/4″ High Temp Glass Filled Nylon
P 300 3NP5X 3 1/4 4″ 6 1/8″
5″ 1 1/4″ High Temp Phenolic – Fiberglass
P 300 3TP5X 3 1/4 4″ 6 1/8″

Wheels for the StemCaster Model 3

Stem Caster Model 3 Features

img Modular Stem Caster capable of using all fastening options seen on this page!
img Swivel Construction – Stamped steel. Swivel has double ball bearing with hardened raceways. Metal cover shields swivel bearings from dirt and dust.
img Axle – 3/8″ diameter bolt with lock nut.
img Center Pin 1/2″ diameter steel rivet
img Finish – external metal parts are Zinc plated.
img Use the Polyolefin ( Industrial Plastic ) wheel for “Standing Loads”. Polyolefin wheels eliminate the possiblilty of a flat spot developing if the castered equipment is left parked for a prolong period.
img Wheel Bearing – PS= Precision Sealed Ball Bearings, B= Ball Bearings, D= Delrin Bearings, P= Plain Bore, RB= Roller Bearing

Use the Polyolefin ( Industrial Plastic ) wheel for “Standing Loads”. Polyolefin wheels eliminate the possiblilty of a flat spot developing on the surfiace of polyurethane and rubber tires when the weight exceeds 2/3 of the rated capacity when the object is left parked most of the time.

Threaded Stem Casters should NOT be used as a “Leveling Device”! Capacity ratings are based on the weight being directly on the top of the swivel bearing, not somewhere above it on the threaded stem.

TB – Top Lock Brake

PTB – Plastic Pedal Top Lock Brake

T-Nuts for Threaded Stems:

T-Nuts can be used to secure our threaded stem casters to wooden items. Here we show the typical use of the T-Nut for both a Horizontal and a Vertical Application.

In the Horizontal Application, you would drill a hole equal to the diameter of the barrel of the T-Nut and completely thru your wood. Hammer the T-Nut into the hole and thread your caster in from the bottom. This is the strongest mounting.

The Vertical Application is for attaching casters to the bottom of legs and into the end grain of the wood. This is not an exceptionally strong way to mount! Drill your hole equal to the diameter of the barrel of the T-Nut and to the depth of the length of the stem of the caster plus about 1/4″. Apply 2 part epoxy to the T-Nut for additional strength. Hammer the T-Nut into the hole and thread your caster in from the bottom. You must use epoxy as we have had problems with some woods where the nuts ( and the casters ) fall off.

Typical Applications:

img Material Handling
img Stocking Carts
img Food Service Carts
img Mobile Workstations
img Office Equipment
img Laboratory Equipment
img Bakery Equipment
img Moving Dollies
img Computer Equipment Stands
img Electronic & Diagnostic Equipment and Carts
img Computer Room Equipment
img Institutional Equipment

Need Help with your order?
(800) 501-3808

You should never select on the basis of load capacity alone. There is no industry standard for load capacity ratings and they may not include a factor for abuse. Our capacity ratings are below what the casters are capable of carrying because most applications have less than perfect conditions. Please refer to the information shown at the bottom of this page. If you have any doubt as to which wheel or caster is the BEST choice for your application contact us for a recommendation.
