Casters for Aerospace Industry

Caster City is a leading manufacturer of heavy duty industrial casters that meet the demands of the Space industry. Caster City offers a large variety of industrial polyurethane caster wheels and high capacity compression molded nylon wheels . These non-metal industrial caster wheels are designed in order to suit your indoor manufacturing needs and protect your flooring. Our casters support the heaviest, toughest loads in the aerospace industry. These casters are built to easily roll indoors and outdoors to accommodate large loads such as rocket modules, aircraft wings, wings, fuselages, parts such as flight tools, cameras, and parachutes, industrial 3d printers, and ground support equipment. Caster City has invested heavily in maintaining hundreds of pieces of every heavy duty wheel industrial caster bracket and wheel we offer on the website / from our catalog. We are ready to overnight ship your heaviest duty needs to support your mission critical operations. We can easily match any heavy duty industrial caster and its specifications manufactured by other caster companies. Contact us for a quote on replacing your casters with our industrial casters.

Most of our customers in the Aerospace Industry order these Casters

The aerospace industry UNIVERSALLY selects its casters based off of mounting plate size / bolt – hole pattern. We recommend that you order our Caster Models 50 and up, which are highlighted in the charts below. We also recommend you only get casters with NX Wheels (Ultra High Capacity Polymer Caster Wheels) and PX or PYH Wheels (Polyurethane Caster Wheels with Iron Centers):

Desktop: When you put your mouse over the words in the wheel description column you see a picture of the wheel. Click on the part number in the Swivel and Rigid columns to see the complete caster.

Mobile: Hold down your finger on the chart and scroll to the right to click on the part number you would like to order.

Filter through the Available Diameters to find the size you need.

CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL STD BRG TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
6″ 2 1/2″ Polyurethane on Iron
 Roller 1600 50PY6X2.50-S 50PY6X2.50-R 23 4 3/4″ 8″
6″ 2 1/2″ Polyurethane on Iron – Slight Crown Tread
 Roller 1600 50PYC6X2.50-S 50PYC6X2.50-R 26 4 3/4″ 8″
6″ 2 1/2″ Phenolic
 Roller 1600 50TH6X2.50-S 50TH6X2.50-R 18 4 3/4″ 8″
6″ 2 1/2″ Ductile Steel
 Roller 3500 50DS6X2.50-S 50DS6X2.50-R 28 4 3/4″ 8″
6″ 2 1/2″ V-Groove Ductile Steel
 Roller 3500 50VS6X2.50-S 50VS6X2.50-R 25 4 3/4″ 8″
6″ 3″ Polyurethane on Iron
 Roller 2000 50PY6X3-S 50PY6X3-R 24 4 3/4″ 8″
6″ 3″ 65D Green Polyurethane on Iron
 Roller 3000 50PYH6X3-S 50PYH6X3-R 31 4 3/4″ 8″
6″ 3″ 65D Green Polyurethane on Iron
 Precision Ball 3000 50PYH6X3PS-S 50PYH6X3PS-R 31 4 3/4″ 8″
6″ 3″ 65D Green Polyurethane on Iron
 Tapered 3000 50PYH6X3T-S 50PYH6X3T-R 31 4 3/4″ 8″
6″ 3″ 95A Orange Premium Polyurethane on Iron
 Tapered 4000 50PX6X3T-S 50PX6X3T-R 31 4 3/4″ 8″
6″ 3″ Polyurethane on Iron – Slight Crown Tread
 Roller 2000 50PYC6X3-S 50PYC6X3-R 30 4 3/4″ 8″
6″ 3″ Phenolic
 Roller 2000 50TH6X3-S 50TH6X3-R 19 4 3/4″ 8″
6″ 3″ Gray Iron
 Roller 1000 50CL6X3-S 50CL6X3-R 23 4 3/4″ 8″
6″ 3″ Ductile Steel
 Roller 5000 50DS6X3-S 50DS6X3-R 30 4 3/4″ 8″
6″ 3″ Ductile Steel*T
 Tapered 5000 50DS6X3T-S 50DS6X3T-R 30 4 3/4″ 8″
6″ 3″ Ductile Steel – Slight Crown
 Roller 5000 50DSC6X3-S 50DSC6X3-R 30 4 3/4″ 8″
6″ 3″ Ductile Steel – Slight Crown*T
 Tapered 5000 50DSC6X3T-S 50DSC6X3T-R 30 4 3/4″ 8″
6″ 3″ Ductile Steel – Slight Crown*B
 Bronze 5000 50DSC6X3BRNZ-S 50DSC6X3BRNZ-R 30 4 3/4″ 8″
6″ 3″ Forged Steel
 Tapered 7000 50FS6X3T-S 50FS6X3T-R 33 4 3/4″ 8″
6″ 3″ Ultra High Capacity Polymer
 Precision Ball 6000 50NX6X3-S 50NX6X3-R 15 4 3/4″ 8″
6″ 3″ V-Groove Gray Iron
 Roller 1000 50VL6X3-S 50VL6X3-R 27 4 3/4″ 8″
6″ 3″ V-Groove Ductile Steel
 Roller 5000 50VS6X3-S 50VS6X3-R 35 4 3/4″ 8″
6″ 3″ Ductile Steel – V Groove*T
 Tapered 5000 50VS6X3T-S 50VS6X3T-R 35 4 3/4″ 8″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL STD BRG TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
8″ 2 1/2″ Polyurethane on Iron
 Roller 1600 50PY8X2.50-S 50PY8X2.50-R 27 6 1/2″ 10 1/2″
8″ 2 1/2″ Polyurethane on Iron – Slight Crown Tread
 Roller 1600 50PYC8X2.50-S 50PYC8X2.50-R 29 6 1/2″ 10 1/2″
8″ 2 1/2″ Phenolic
 Roller 1600 50TM8X2.50-S 50TM8X2.50-R 21 6 1/2″ 10 1/2″
8″ 2 1/2″ Ductile Steel
 Roller 3500 50DS8X2.50-S 50DS8X2.50-R 30 6 1/2″ 10 1/2″
8″ 2 1/2″ V-Groove Ductile Steel
 Roller 3500 50VS8X2.50-S 50VS8X2.50-R 30 6 1/2″ 10 1/2″
8″ 3″ Polyurethane on Iron
 Roller 2500 50PY8X3-S 50PY8X3-R 28 6 1/2″ 10 1/2″
8″ 3″ 65D Green Polyurethane on Iron
 Roller 3500 50PYH8X3-S 50PYH8X3-R 35 6 1/2″ 10 1/2″
8″ 3″ 65D Green Polyurethane on Iron
 Tapered 3500 50PYH8X3T-S 50PYH8X3T-R 35 6 1/2″ 10 1/2″
8″ 3″ 95A Orange Premium Polyurethane on Iron
 Tapered 5000 50PX8X3T-S 50PX8X3T-R 35 6 1/2″ 10 1/2″
8″ 3″ Polyurethane on Iron – Slight Crown Tread
 Roller 2500 50PYC8X3-S 50PYC8X3-R 35 6 1/2″ 10 1/2″
8″ 3″ Phenolic
 Roller 2500 50TM8X3-S 50TM8X3-R 22 6 1/2″ 10 1/2″
8″ 3″ Gray Iron
 Roller 1000 50CL8X3-S 50CL8X3-R 27 6 1/2″ 10 1/2″
8″ 3″ Ductile Steel – FLAT
 Roller 5000 50DS8X3-S 50DS8X3-R 38 6 1/2″ 10 1/2″
8″ 3″ Ductile Steel – Slight Crown
 Roller 5000 50DSC8X3-S 50DSC8X3-R 38 6 1/2″ 10 1/2″
8″ 3″ Ductile Steel – Slight Crown*T
 Tapered 5000 50DSC8X3T-S 50DSC8X3T-R 38 6 1/2″ 10 1/2″
8″ 3″ Ductile Steel – Slight Crown*B
 Bronze 5000 50DSC8X3BRNZ-S 50DSC8X3BRNZ-R 38 6 1/2″ 10 1/2″
8″ 3″ Forged Steel
 Tapered 7000 50FS8X3T-S 50FS8X3T-R 48 6 1/2″ 10 1/2″
8″ 3″ Ultra High Capacity Polymer
 Precision Ball 6000 50NX8X3-S 50NX8X3-R 18 6 1/2″ 10 1/2″
8″ 3″ V-Groove Gray Iron
 Roller 1000 50VL8X3-S 50VL8X3-R 28 6 1/2″ 10 1/2″
8″ 3″ V-Groove Ductile Steel
 Roller 5000 50VS8X3-S 50VS8X3-R 38 6 1/2″ 10 1/2″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL STD BRG TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
10″ 2 1/2″ Polyurethane on Iron
 Roller 1600 50PY10X2.50-S 50PY10X2.50-R 33 8 1/32″ 12 1/2″
10″ 2 1/2″ Polyurethane on Iron – Slight Crown Tread
 Roller 1600 50PYC10X2.50-S 50PYC10X2.50-R 35 8 1/32″ 12 1/2″
10″ 2 1/2″ Phenolic
 Roller 1600 50TM10X2.50-S 50TM10X2.50-R 33 8 1/32″ 12 1/2″
10″ 3″ Polyurethane on Iron
 Roller 3000 50PY10X3-S 50PY10X3-R 35 8 1/32″ 12 1/2″
10″ 3″ 65D Green Polyurethane on Iron
 Roller 4000 50PYH10X3-S 50PYH10X3-R 37 8 1/32″ 12 1/2″
10″ 3″ 65D Green Polyurethane on Iron
 Tapered 4000 50PYH10X3T-S 50PYH10X3T-R 37 8 1/32″ 12 1/2″
10″ 3″ 95A Orange Premium Polyurethane on Iron
 Tapered 5500 50PX10X3T-S 50PX10X3T-R 37 8 1/32″ 12 1/2″
10″ 3″ Polyurethane on Iron – Slight Crown Tread
 Roller 2500 50PYC10X3-S 50PYC10X3-R 35 8 1/32″ 12 1/2″
10″ 3″ Phenolic
 Roller 2500 50TM10X3-S 50TM10X3-R 25 8 1/32″ 12 1/2″
10″ 3″ Gray Iron
 Roller 1000 50CL10X3-S 50CL10X3-R 35 8 1/32″ 12 1/2″
10″ 3″ Ductile Steel
 Roller 6000 50DS10X3-S 50DS10X3-R 45 8 1/32″ 12 1/2″
10″ 3″ Ductile Steel Slight Crown
 Roller 6000 50DSC10X3-S 50DSC10X3-R 45 8 1/32″ 12 1/2″
10″ 3″ Forged Steel
 Tapered 5000 50FS10X3T-S 50FS10X3T-R 45 8 1/32″ 12 1/2″
10″ 3″ Ultra High Capacity Polymer
 Precision Ball 6000 50NX10X3-S 50NX10X3-R 23 8 1/32″ 12 1/2″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL STD BRG TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
12″ 3″ Polyurethane on Iron
 Roller 3500 50PY12X3-S 50PY12X3-R 37 10 1/32″ 15 1/2″
12″ 3″ 65D Green Polyurethane on Iron
 Roller 4000 50PYH12X3-S 50PYH12X3-R 43 10 1/32″ 15 1/2″
12″ 3″ 65D Green Polyurethane on Iron
 Tapered 4500 50PYH12X3T-S 50PYH12X3T-R 43 10 1/32″ 15 1/2″
12″ 3″ 95A Orange Premium Polyurethane on Iron
 Tapered 6500 50PX12X3T-S 50PX12X3T-R 37 10 1/32″ 15 1/2″
12″ 3″ Polyurethane on Iron – Slight Crown Tread
 Roller 3000 50PYC12X3-S 50PYC12X3-R 49 10 1/32″ 15 1/2″
12″ 3″ Phenolic
 Roller 3000 50TM12X3-S 50TM12X3-R 28 10 1/32″ 15 1/2″
12″ 3″ Gray Iron
 Roller 1000 50CL12X3-S 50CL12X3-R 39 10 1/32″ 15 1/2″
12″ 3″ Ductile Steel
 Roller 5000 50DS12X3-S 50DS12X3-R 52 10 1/32″ 15 1/2″
12″ 3″ Ultra High Capacity Polymer
 Roller 6000 50NX12X3-S 50NX12X3-R 28 10 1/32″ 15 1/2″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL STD BRG TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
6″ 3″ Ductile Steel – Flat
 Tapered 10,000 100DS6X3T-S 100DS6X3T-R 35 4 3/4″ 8 1/2″
6″ 3″ V-Groove Ductile Steel
 Tapered 8,000 100VS6X3T-S 100VS6X3T-R 31 4 3/4″ 8 1/2″
6″ 3″ Forged Steel
 Tapered 10,000 100FS6X3T-S 100FS6X3T-R 43 4 3/4″ 8 1/2″
6″ 3″ Ultra High Capacity Polymer
 Precision Ball 7,200 100NX6X3-S 100NX6X3-R 28 4 3/4″ 8 1/2″
6″ 3″ 65D Green Polyurethane on Iron
 Tapered 3,000 100PYH6X3T-S 100PYH6X3T-R 35 4 3/4″ 8 1/2″
6″ 3″ 95A Orange Premium Polyurethane on Iron
 Tapered 3,200 100PX6X3T-S 100PX6X3T-R 35 4 3/4″ 8 1/2″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL STD BRG TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
8″ 3″ Forged Steel
 Tapered 10,000 100FS8X3T-S 100FS8X3T-R 61 6 3/16″ 10 1/2″
8″ 3″ Ultra High Capacity Polymer
 Precision Ball 7,200 100NX8X3-S 100NX8X3-R 31 6 3/16″ 10 1/2″
8″ 3″ 65D Green Polyurethane on Iron
 Tapered 3,500 100PYH8X3T-S 100PYH8X3T-R 40 6 3/16″ 10 1/2″
8″ 3″ 95A Orange Premium Polyurethane on Iron
 Tapered 4,200 100PX8X3T-S 100PX8X3T-R 40 6 3/16″ 10 1/2″
8″ 4″ Ductile Steel – Flat
 Tapered 15,000 100DS8X4T-S 100DS8X4T-R 46 6 3/16″ 10 1/2″
8″ 4″ Forged Steel
 Tapered 15,000 100FS8X4T-S 100FS8X4T-R 65 6 3/16″ 10 1/2″
8″ 4″ Ultra High Capacity Polymer
 Precision Ball 8,000 100NX8X4-S 100NX8X4-R 35 6 3/16″ 10 1/2″
8″ 4″ 65D Green Polyurethane on Iron
 Tapered 4,000 100PYH8X4T-S 100PYH8X4T-R 48 6 3/16″ 10 1/2″
8″ 4″ 95A Orange Premium Polyurethane on Iron
 Tapered 5,000 100PX8X4T-S 100PX8X4T-R 54 6 3/16″ 10 1/2″
8″ 4″ Forged Steel V-Groove
 Tapered 15,000 100VF8X4T-S 100VF8X4T-R 65 6 3/16″ 10 1/2″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL STD BRG TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
10″ 3″ Forged Steel
 Tapered 10,000 100FS10X3T-S 100FS10X3T-R 57 7 11/16″ 12 1/2″
10″ 3″ Ultra High Capacity Polymer
 Precision Ball 7,200 100NX10X3-S 100NX10X3-R 35 7 11/16″ 12 1/2″
10″ 3″ 65D Green Polyurethane on Iron
 Tapered 4,000 100PYH10X3T-S 100PYH10X3T-R 48 7 11/16″ 12 1/2″
10″ 3″ 95A Orange Premium Polyurethane on Iron
 Tapered 4,700 100PX10X3T-S 100PX10X3T-R 48 7 11/16″ 12 1/2″
10″ 4″ Ductile Steel – Flat
 Tapered 15,000 100DS10X4T-S 100DS10X4T-R 71 7 11/16″ 12 1/2″
10″ 4″ Forged Steel
 Tapered 15,000 100FS10X4T-S 100FS10X4T-R 78 7 11/16″ 12 1/2″
10″ 4″ Ultra High Capacity Polymer
 Precision Ball 8,000 100NX10X4-S 100NX10X4-R 39 7 11/16″ 12 1/2″
10″ 4″ 65D Green Polyurethane on Iron
 Tapered 5,500 100PYH10X4T-S 100PYH10X4T-R 60 7 11/16″ 12 1/2″
10″ 4″ 95A Orange Premium Polyurethane on Iron
 Tapered 6,000 100PX10X4T-S 100PX10X4T-R 62 7 11/16″ 12 1/2″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL STD BRG TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
12″ 3″ Ultra High Capacity Polymer
 Precision Ball 7,200 100NX12X3-S 100NX12X3-R 40 9 5/8″ 15 1/2″
12″ 3″ 65D Green Polyurethane on Iron
 Tapered 4,500 100PYH12X3T-S 100PYH12X3T-R 54 9 5/8″ 15 1/2″
12″ 3″ 95A Orange Premium Polyurethane on Iron
 Tapered 6,500 100PX12X3T-S 100PX12X3T-R 68 9 5/8″ 15 1/2″
12″ 4″ Ductile Steel – Flat
 Tapered 15,000 100DS12X4T-S 100DS12X4T-R 83 9 5/8″ 15 1/2″
12″ 4″ Ultra High Capacity Polymer
 Precision Ball 8,000 100NX12X4-S 100NX12X4-R 46 9 5/8″ 15 1/2″
12″ 4″ 65D Green Polyurethane on Iron
 Tapered 6,500 100PYH12X4T-S 100PYH12X4T-R 72 9 5/8″ 15 1/2″
12″ 4″ 95A Orange Premium Polyurethane on Iron
 Tapered 7,000 100PX12X4T-S 100PX12X4T-R 72 9 5/8″ 15 1/2″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL Click below for Replacement Wheels STD BRG TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
8″ 4″ Ductile Steel
 Tapered 15,000 150DS8X4T-S 150DS8X4T-R 57 6″ 11″
8″ 4″ Forged Steel
 Tapered 20,000 150FS8X4T-S 150FS8X4T-R 72 6″ 11″
8″ 4″ Ultra High Capacity Polymer
 Precision Ball 8,000 150NX8X4-S 150NX8X4-R 43 6″ 11″
8″ 4″ 65D Green Polyurethane on Iron
 Tapered 4,000 150PYH8X4T-S 150PYH8X4T-R 61 6″ 11″
8″ 4″ 95A Orange Premium Polyurethane on Iron
 Tapered 5,000 150PX8X4T-S 150PX8X4T-R 61 6″ 11″
8″ 4″ Forged Steel V-Groove
 Tapered 15,000 150VF8X4T-S 150VF8X4T-R 70 6″ 11″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL Click below for Replacement Wheels STD BRG TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
10″ 4″ Ductile Steel
 Tapered 15,000 150DS10X4T-S 150DS10X4T-R 76 7 1/2″ 13″
10″ 4″ Forged Steel
 		Tapered 20,000 150FS10X4T-S 150FS10X4T-R 85 7 1/2″ 13″
10″ 4″ Ultra High Capacity Polymer
 Precision Ball 8,000 150NX10X4-S 150NX10X4-R 48 7 1/2″ 13″
10″ 4″ 65D Green Polyurethane on Iron
 Tapered 5,000 150PYH10X4T-S 150PYH10X4T-R 69 7 1/2″ 13″
10″ 4″ 95A Orange Premium Polyurethane on Iron
 Tapered 6,000 150PX10X4T-S 150PX10X4T-R 69 7 1/2″ 13″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL Click below for Replacement Wheels STD BRG TYPE MAX CAP. EACH CASTER LBS SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
12″ 4″ Ductile Steel
 Tapered 15,000 150DS12X4T-S 150DS12X4T-R 104 9″ 15 1/2″
12″ 4″ Forged Steel
 Tapered 20,000 150FS12X4T-S 150FS12X4T-R 134 9″ 15 1/2″
12″ 4″ Ultra High Capacity Polymer
 Precision Ball 8,000 150NX12X4-S 150NX12X4-R 55 9″ 15 1/2″
12″ 4″ 65D Green Polyurethane on Iron
 Tapered 6,000 150PYH12X4T-S 150PYH12X4T-R 79 9″ 15 1/2″
12″ 4″ 95A Orange Premium Polyurethane on Iron
 Tapered 8,000 150PX12X4T-S 150PX12X4T-R 79 9″ 15 1/2″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL Click below for Replacement Wheels BEARING TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
6″ 3″ 65D Green Polyurethane on Iron
 T 6,000 2-50PYH6X3T-S 2-50PYH6X3T-R 43 6 3/8″ 8 1/16″
6″ 3″ 95A Orange Premium Polyurethane on Iron
 		T 6,400 2-50PX6X3T-S 2-50PX6X3T-R 43 6 3/8″ 8 1/16″
6″ 3″ Ultra High Capacity Polymer
 PS 6,000 2-50NX6X3-S 2-50NX6X3-R 33 6 3/8″ 8 1/16″
6″ 3″ Forged Steel
 		T 7,000 2-50FS6X3T-S 2-50FS6X3T-R 58 6 3/8″ 8 1/16″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL Click below for Replacement Wheels BEARING TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
8″ 3″ 65D Green Polyurethane on Iron
 T 7,000 2-50PYH8X3T-S 2-50PYH8X3T-R 53 7 7/8″ 10 1/2″
8″ 3″ 95A Orange Premium Polyurethane on Iron
 T 7,000 2-50PX8X3T-S 2-50PX8X3T-R 54 7 7/8″ 10 1/2″
8″ 3″ Ultra High Capacity Polymer
 PS 7,000 2-50NX8X3-S 2-50NX8X3-R 45 7 7/8″ 10 1/2″
8″ 3″ Forged Steel
 		T 7,000 2-50FS8X3T-S 2-50FS8X3T-R 96 7 7/8″ 10 1/2″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL Click below for Replacement Wheels BEARING TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
10″ 3″ 65D Green Polyurethane on Iron
 T 7,000 2-50PYH10X3T-S 2-50PYH10X3T-R 69 9 1/2″ 12 1/2″
10″ 3″ 95A Orange Premium Polyurethane on Iron
 T 7,000 2-50PX10X3T-S 2-50PX10X3T-R 69 9 1/2″ 12 1/2″
10″ 3″ Ultra High Capacity Polymer
 PS 7,000 2-50NX10X3-S 2-50NX10X3-R 58 9 1/2″ 12 1/2″
10″ 3″ Forged Steel
 		T 7,000 2-50FS10X3T-S 2-50FS10X3T-R 87 9 1/2″ 12 1/2″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL Click below for Replacement Wheels BEARING TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
12″ 3″ 65D Green Polyurethane on Iron
 T 7,000 2-50PYH12X3T-S 2-50PYH12X3T-R 69 9 1/2″ 12 1/2″
12″ 3″ Ultra High Capacity Polymer
 PS 7,000 2-50NX12X3-S 2-50NX12X3-R 97 9 1/2″ 12 1/2″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL Click below for Replacement Wheels BEARING TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
6″ 3″ 65D Green Polyurethane on Iron
 T 6,000 2-100PYH6X3T-S 2-100PYH6X3T-R 51 6 1/8″ 8 27/32″
6″ 3″ 95A Orange Premium Polyurethane on Iron
 T 7,200 2-100PX6X3T-S 2-100PX6X3T-R 53 6 1/8″ 8 27/32″
6″ 3″ Ultra High Capacity Polymer
 		PS 14,000 2-100NX6X3-S 2-100NX6X3-R 45 6 1/8″ 8 27/32″
6″ 3″ Forged Steel
 		T 15,000 2-100FS6X3T-S 2-100FS6X3T-R 69 6 1/8″ 8 27/32″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL Click below for Replacement Wheels BEARING TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
8″ 3″ 65D Green Polyurethane on Iron
 		T 7,000 2-100PYH8X3T-S 2-100PYH8X3T-R 68 7 3/4″ 10 7/8″
8″ 3″ 95A Orange Premium Polyurethane on Iron
 		T 11,000 2-100PX8X3T-S 2-100PX8X3T-R 63 7 3/4″ 10 7/8″
8″ 3″ Ultra High Capacity Polymer
 PS 14,000 2-100NX8X3-S 2-100NX8X3-R 63 7 3/4″ 10 7/8″
8″ 3″ Forged Steel
 T 15,000 2-100FS8X3T-S 2-100FS8X3T-R 105 7 3/4″ 10 7/8″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL Click below for Replacement Wheels BEARING TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
10″ 3″ 65D Green Polyurethane on Iron
 T 8,000 2-100PYH10X3T-S 2-100PYH10X3T-R 78 9 1/4″ 12 13/16″
10″ 3″ 95A Orange Premium Polyurethane on Iron
 T 12,000 2-100PX10X3T-S 2-100PX10X3T-R 78 9 1/4″ 12 13/16″
10″ 3″ Ultra High Capacity Polymer
 PS 14,000 2-100NX10X3-S 2-100NX10X3-R 66 9 1/4″ 12 13/16″
10″ 3″ Forged Steel
 T 15,000 2-100FS10X3T-S 2-100FS10X3T-R 96 9 1/4″ 12 13/16″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL Click below for Replacement Wheels BEARING TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
12″ 3″ Polyurethane on Iron – Heavy Duty
 T 10,000 2-100PYH12X3T-S 2-100PYH12X3T-R 89 11 1/4″ 15 1/2″
12″ 3″ Ultra High Capacity Polymer
 PS 14,000 2-100NX12x3-S 2-100NX12X3-R 76 11 1/4″ 15 1/2″
12″ 3″ Ductile Steel
 T 15,000 2-100DS12X3T-S 2-100DS12X3T-R 96 11 1/4″ 15 1/2″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL BEARING TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
8″ 4″ 65D Green Polyurethane on Iron
 T 8,000 2-150PYH8X4T-S 2-150PYH8X4T-R 92 7 3/4″ 11″
8″ 4″ 95A Orange Premium Polyurethane on Iron
 T 13,000 2-150PX8X4T-S 2-150PX8X4T-R 107 7 3/4″ 11″
8″ 4″ Ultra High Capacity Polymer
 PS 16,000 2-150NX8X4-S 2-150NX8X4-R 62 7 3/4″ 11″
8″ 4″ Forged Steel
 T 30,000 2-150FS8X4T-S 2-150FS8X4T-R 126 7 3/4″ 11″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL BEARING TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
10″ 4″ 65D Green Polyurethane on Iron
 T 11,000 2-150PYH10X4T-S 2-150PYH10X4T-R 112 9 14″ 13″
10″ 4″ 95A Orange Premium Polyurethane on Iron
 T 15,000 2-150PX10X4T-S 2-150PX10X4T-R 123 9 14″ 13″
10″ 4″ Ultra High Capacity Polymer
 PS 16,000 2-150NX10X4-S 2-150NX10X4-R 74 9 14″ 13″
10″ 4″ Forged Steel
 T 30,000 2-150FS10X4T-S 2-150FS10X4T-R 152 9 14″ 13″
CASTER WHEEL DIAM. TREAD WIDTH WHEEL TREAD MATERIAL BEARING TYPE MAX CAP. EACH CASTER LBS. SWIVEL CASTER Part Number RIGID CASTER Part Number APPROX SWIVEL WEIGHT (LBS) APPROX SWIVEL RADIUS OVERALL HEIGHT
12″ 4″ 65D Green Polyurethane on Iron
 T 13,000 2-150PYH12X4T-S 2-150PYH12X4T-R 135 11″ 15 1/2″
12″ 4″ 95A Orange Premium Polyurethane on Iron
 T 16,000 2-150PX12X4T-S 2-150PX12X4T-R 145 11″ 15 1/2″
12″ 4″ Ultra High Capacity Polymer
 PS 16,000 2-150NX12X4-S 2-150NX12X4-R 85 11″ 15 1/2″
12″ 4″ Forged Steel
 T 40,000 2-150FS12X4T-S 2-150FS12X4T-R 247 11″ 15 1/2″

Need Help with your order?
(800) 501-3808

You should never select on the basis of load capacity alone. There is no industry standard for load capacity ratings and they may not include a factor for abuse. Our capacity ratings are below what the casters are capable of carrying because most applications have less than perfect conditions. Please refer to the information shown at the bottom of this page. If you have any doubt as to which wheel or caster is the BEST choice for your application contact us for a recommendation.

Click to Call Now
