Road Case Casters

The blue tire (tread) on the Road Case Caster wheel is a flexible elastomer. What makes this elastomer special is its ability to bounce. Resilience in a wheel material is a necessary feature in order to protect the cargo being moved. The tire on this wheel is a resilient synthetic elastic rubber. It provides the performance of a cushion ride without the expense associated with a tire made using natural rubber. The tire is chemically bonded to a heavy duty impact resistant industrial grade polyolefin core (center).
The Road Case Caster wheel got its name because it was specifically designed to withstand the kind of conditions road cases are typically exposed to. It will roll over cords, thresholds, up and down ramps, over uneven surfaces such as asphalt and truck ramps, and other obstructions. This wheel is also great for other applications such as to move lighting fixtures, computers, and audio visual equipment. It is the 4″ diameter wheel of choice for many applications in Scientific and Electronic Laboratories, TV and Movie Studios, Hospitals, Hotels, and Department Stores. The Road Case Caster wheel is ideally suited to move fragile or delicate cargo, and wherever noise and vibration should be reduced.

We install the Road Case Caster wheel in zinc plated corrosion resistant steel caster frames with a choice of 3 different mounting plate sizes. The swivel caster frames shown with a metric mounting plate have a seal on the swivel bearing. The other caster frames have the swivel protected by a metal cover. The swivel section under the mounting plates consist of two rows of ball bearings for easy rotation. Two types of brakes are optional. The Total Lock brake locks the swivel and the wheel simultaneously. The casters with the brake pedal on the side of the wheel lock only the wheel.

The Road Case Caster wheel comes only in a 4″ diameter. If you need a 5″ or  6″ or 8″ diameter wheel with the same performance characteristics as the Road Case Caster wheel check out our Blue Ergonomic Rubber Caster Wheels.

Road Case Casters Features:

img Synthetic elastic rubber tire
img Resilient Cushion ride
img Non-marking
img Tear resistant
img Can roll over small obstructions
img Protects cargo and equipment
img Impact resistant
img Minimizes vibration
img Reduces noise
img Anti-friction Roller Bearing in the wheel
img Corrosion resistant Zinc plated caster frames
img Double ball bearing swivels
img 3 choices of mounting plate sizes
img Capacity: 350 Lbs per caster
img Caster Overall Height: 5-1/4″
img Swivel Radius: 3-1/2″ without brake, 4-1/2″ with brake

Road Case Casters with 4″ Rubber Wheel – Mounting Plate 85 mm x 104 mm

Road Case Casters with 4″ Rubber Wheel – Mounting Plate 3 1/8″ x 4 1/8″

Road Case Casters with 4″ Rubber Wheel – Mounting Plate 3 1/8″ x 4 1/8″

Need Help with your order?
(800) 501-3808

You should never select on the basis of load capacity alone. There is no industry standard for load capacity ratings and they may not include a factor for abuse. Our capacity ratings are below what the casters are capable of carrying because most applications have less than perfect conditions. Please refer to the information shown at the bottom of this page. If you have any doubt as to which wheel or caster is the BEST choice for your application contact us for a recommendation.
